Assembly-level OEM support for custom robot servo actuators, including mechanical assembly, calibration, load testing, burn-in, and outgoing inspection records.
| Program Metric | Typical Range | Procurement Value |
|---|---|---|
| Outgoing test scope | Functional, load, temperature, backlash, communication | Assembly-level evidence reduces buyer-side debugging and field failure risk. |
| Calibration point | Encoder zero, current offset, travel limit, torque check | Repeatable calibration makes robot-side assembly faster and keeps units consistent across pilot lots. |
| Burn-in profile | No-load, load cycle, thermal soak, communication cycling | Burn-in catches assembly, cabling, firmware, and thermal issues before the actuator reaches the buyer. |
| Situation | Recommended Path | Evidence to Confirm |
|---|---|---|
| The buyer has a motor, reducer, drive, and encoder BOM but no repeatable assembly path | Define assembly datum, torque sequence, preload, adhesive/locking method, calibration, and EOL fixture checks | Exploded BOM, torque specs, critical datums, fixture concept, calibration routine, and operator checklist |
| Robot-side debugging is too slow after receiving samples | Ship each actuator with serialized calibration, load test, communication check, and outgoing inspection evidence | Serial number, encoder zero, travel limit, current offset, torque/speed data, temperature log, and firmware version |
| Actuators are damaged by handling, harness strain, or packaging | Treat cable strain relief, connector caps, labels, shock protection, and shipment orientation as QA requirements | Packaging spec, drop or vibration assumption, cable protection, label format, and receiving inspection checklist |
| Checkpoint | Method | Pass Evidence |
|---|---|---|
| Assembly fixture readiness | Confirm datums, preload, torque sequence, adhesive/locking steps, calibration fixture, and EOL fixture | Fixture checklist, work instruction, torque standard, and critical-datum inspection record |
| EOL functional validation | Test current, speed, torque, backlash, encoder zero, travel limits, communication, noise, and heat rise | Serialized EOL report and calibration data for each actuator |
| Outgoing packaging control | Inspect cable protection, connector caps, labels, shock packaging, shipment orientation, and receiving checklist | Packaging approval and outgoing inspection record tied to batch and serial numbers |
Program Evidence
For OEM pages, the first engineering review defines execution gates, missing data, and production-readiness evidence before kickoff.
Motor, drive, actuator, firmware, harness, fixture, and test responsibility are separated before quotation.
Open items such as torque-speed data, duty cycle, envelope, protocol, encoder, and target launch country are flagged early.
Prototype checks are tied to load profile, thermal rise, backlash, noise, current limit, and end-of-line pass criteria.
Tooling, fixture, pilot lot, annual forecast, packaging, documentation, and delivery assumptions are made explicit.
| Evidence Group | What to Attach | Buyer Value |
|---|---|---|
| Motion and thermal | Torque-speed target, current limit, duty cycle, temperature path, and derating assumption. | Separates continuous-duty capability from peak torque claims before sample approval. |
| Interface control | STEP or drawing revision, flange, bore, cable exit, connector, encoder, and protocol map. | Keeps motor, drive, harness, and firmware assumptions aligned before tooling. |
| Validation record | EVT, DVT, PVT gate criteria, EOL checklist, burn-in profile, and serial or lot traceability. | Gives engineering and procurement a common pass/fail basis for pilot lots. |
| Commercial path | Prototype quantity, pilot build target, annual forecast, delivery country, and packing notes. | Improves quote precision and avoids late shipping or documentation surprises. |
Yes. Assembly and test scope can be defined from drawings, BOM, firmware, and acceptance criteria.
Yes. Serial numbers, calibration data, load-test results, communication checks, and inspection records can be aligned before pilot build.
